CKM_AES_ECB_ENCRYPT_DATA
Supported Operations
|
Encrypt and Decrypt |
No |
|
Sign and Verify |
No |
|
SignRecover and VerifyRecover |
No |
|
Digest |
No |
|
Generate Key/Key-Pair |
No |
|
Wrap and Unwrap |
No |
|
Derive |
Yes |
|
Available in FIPS Mode |
No |
Key Size Range (bytes) and Parameters
| Minimum | 16 |
| Maximum | 32 |
| Parameter | Data to be encrypted |
Description
This mechanism functions as described in the PKCS#11 version 2.20 documentation from RSA Laboratories, with the following exception:
CAUTION! PKCS#11 version 2.20 points to a CK_KEY_DERIVATION_STRING_DATA structure. If this structure is passed as a parameter, it contains pointers to the data located in host memory, and the HSM will crash during execution.
Figure 1: CKM_AES_ECB_ENCRYPT_DATA mechanism
