Figure 1: PKCS#11 Logger Architecture Model
The logger is interposed between the application and the SafeNet ProtectToolkit-C host library. There, it intercepts PKCS#11 function calls and responses. Details are logged to the log file before the messages are passed through to their intended destination.
For each PKCS#11 call, the logger creates an entry in the log file. By default, these entries contain the following details:
•the calling process ID (PID)
•the thread ID (TID)
•the date and time of the call
•all numeric data
•buffer addresses
•contents of buffer addresses at the input and output of functions (excluding PIN values)
Optionally, the logger may be configured to:
•return the PIN values used to login to tokens that are provided to the C_Login function
•remove any or all of the following from the output:
•the calling process ID (PID)
•the thread ID (TID)
•the date and time of the call
•contents of buffer addresses at the input and output of functions
