Migrate from Data Security Manager
You can restore the following objects from a Data Security Manager (DSM) 6.4.5 backup file using the CipherTrust Manager CLI tool ksctl:
Agent keys, including versioned keys and KMIP accessible keys.
Bring Your Own Key (BYOK) objects
Clients and client GuardPoints
Client groups and client group GuardPoints
Clients and client group associations
User sets, resource sets, signature sets, and signatures
Standard, Cloud Object Storage (COS), and In-place Data Transformation (IDT) policies
Client logging, upload logging, and Syslog settings
LDT Quality of Service (QOS) and QOS schedules
The DSM Administration Guide version 6.4.5 describes creating and encrypting a backup file for CipherTrust Manager in Chapter 12 "Backing Up and Restoring".
Some objects present in the backup file are skipped during restore. The skipped objects include:
Most Key Management Interoperability Protocol (KMIP) keys, except for KMIP-accessible agent keys
Keys associated with Ciphertrust Cloud Key Manager (CCKM), including Key Management as a Service (KMaaS) keys
DSM hostname and host configuration
Live Data Transformation (LDT) policies
In future releases, we plan to add support for the following CTE-related items:
Client and Client Group password management
Common Internet File System (CIFS)
Efficient storage device (ESG)
Object Permissions After Migration
By default, the user who restores the backup file becomes the administrator of the newly created CipherTrust Manager domain(s), and has access to the restored keys within the domain(s). There is an additional option to create a key-sharing group with permissions for the restored keys in all domains. You can later add CipherTrust Manager users to this group to grant access to the keys.
In addition, the optional parameter
auto-cte-groups induces CipherTrust Manager to automatically detect CTE keys and grant permission to access these keys to members of the
CTE Clients group on CipherTrust Manager.
Migrating KMIP Accessible Agent Keys
In DSM, KMIP accessible agent keys created on DSM have two copies. One copy is included in the DSM backup file, and can be restored on CipherTrust Manager with the ksctl CLI. The other copy is stored as a KMIP object, and displayed in Keys > KMIP objects on the DSM UI. CipherTrust Manager only retains one copy of the key after migration.
A separate client utility can migrate all objects displayed in Keys > KMIP Objects, including agent key copies. This utility connects directly to KMIP interfaces on both key managers instead of acting on the backup file.
KMIP accessible agent keys are the only type of DSM object which can be migrated through both the client utility and ksctl. Both processes are idempotent, so migrating the same key object twice does not overwrite the key on CipherTrust Manager.
We recommend migrating KMIP accessible agent keys through ksctl.
CipherTrust Manager Changes from Thales eSecurity DSM
No hypervisor limitation - so it can run on any cloud
Improved User Interface
Updated REST interface that offers both encryption and configuration in scope
Addition of a full-featured, remote CLI interface
Embedded CipherTrust Cloud Key Manager (removes the need for seperate MongoDB instance)
Unified Key Management with KMIP key material - integrates policy, logging and management - bringing simplified and richer capabilities to KMIP
Supports CipherTrust Transparent Encryption/CTE (renamed from VTE/Vormetric Transparent Encryption) from version 7.0
Supports CipherTrust Application Data Protection (CADP) as a replacement for Vormetric Application Encryption (VAE) and Vormetric Key Management (VKM)
All other connectors (Batch Data Transformation/BDT and Tokenization) are supported with latest versions
Exporting and Importing the Backup File
As part of exporting a backup file from a DSM, you create a wrapper key to encrypt the file. On the target CipherTrust Manager, you create a migration split key with the same values as the wrapper key. This migration split key is needed for CipherTrust Manager to decrypt the backup file to restore the DSM objects.
The wrapper key and migration split key divides a single key into multiple shares, with a minimum number of shares required to reassemble the key. This configuration, called M of N, provides more security as a different custodian holds and controls each share.
To migrate objects from DSM
On your DSM appliance, create a wrapper key, and split it into key shares as described in the DSM Administration Guide version 6.4.5 Chapter 12 "Backing Up and Restoring".
You need the following values to later create the corresponding migration split key and key shares on CipherTrust Manager:
The wrapper key identifier
The Minimum Custodians Needed to assemble the wrapper key
The key material from the wrapper key shares
Create a backup file on the DSM, using the wrapper key to encrypt the backup file.
The backup file can include objects that are not yet supported for migration to CipherTrust Manager. CipherTrust Manager skips these unsupported items and does not restore them.
In some cases, the download of the DSM migration data might fail.
To work around this issue:
1. Run the DSM CLI commands
2. Retry the backup download.
Create a migration split key on a CipherTrust Manager to decrypt the backup file.
You cannot directly import a DSM-created wrapper key into the CipherTrust Manager. You must re-create the wrapper key as a migration split key.
Create the migration split key.
$ ksctl migration-split-keys create --name <name> --threshold <threshold> --digest <digest>
You must provide:
namefor the key.
threshold— a minimum number of keys needed to reconstruct the split key, based on Minimum Custodians Needed from the DSM wrapper key.
digest— the identifier from the original DSM wrapper key.
Create shares for the split key. Create as many as shares as indicated in the
thresholdvalue for the migration split key.
$ ksctl migration-split-keys shares create --name <name> --share-key <share-key> $ ksctl migration-split-keys shares create --name <name> --share-key <share-key>
You must provide the name of the migration split key and the key material from the DSM wrapper key share.
Upload the backup file into the CipherTrust Manager. Take note of the ID returned in the response.
$ ksctl migrations upload --file <filename>
Apply the backup file.
$ ksctl migrations apply --id <id> [--user <user-name> --password <user-password>] [--domains <DSM-domains>] [--group-name <DSM group name>] [--auto-cte-groups]
You must provide the
idfor the backup file. This was indicated when you uploaded the backup, or you can view it with the
ksctl migrations listcommand.
The following parameters are optional:
user— The CipherTrust Manager user who will become the administrator of the created domain(s). If not specified, the user currently logged in to ksctl is granted this permission.
password— Password of the above CipherTrust Manager user.
domains— Limits the DSM domains that are restored. The accepted format is a comma-separate list of domain names.
group-name— Creates a new group with this name in every domain that is migrated. Users belonging to this group can access all keys in the domain.
auto-cte-groups— When present, automatically detects CTE keys and grants permission to access these keys to members of the
CTE Clientsgroup on CipherTrust Manager. If you are migrating CTE clients from DSM to CipherTrust Manager, we highly recommend including this parameter to ensure continuity of CTE client access to keys.
You can check the status of the migration with
ksctl migration status.
List your keys to ensure that DSM keys were successfully migrated into the CipherTrust Manager domain.
$ ksctl --domain <domain-name> keys list
If you are migrating CTE configuration from a DSM to the CipherTrust Manager, then after the DSM is migrated successfully, you need to perform additional steps for the CTE clients. Refer to Migrating CTE Configuration from Data Security Manager for details.
